ACD-800B Chelating Resin Sodium Sulfide Caustic Regeneration Gallium Elution 3.5g/L
Product Details:
| Place of Origin: | China |
| Brand Name: | ADVSORBENT |
| Certification: | ISO 9001:2015 |
| Model Number: | ACD-800B |
Payment & Shipping Terms:
| Minimum Order Quantity: | 25 Liters |
|---|---|
| Price: | USD 30-60 / Liter |
| Packaging Details: | 25 liters/bag, 25KG/bag, 50 liters/drum (dry type), 200 liters/drum, 1 cbm on a pallet, 1 ton on a pallet, or customized |
| Delivery Time: | 7-15 working days after order confirmation |
| Payment Terms: | T/T, L/C, Western Union, PayPal |
| Supply Ability: | 1000 Tons per Year |
|
Detail Information |
|||
| Structure: | Styrene-Acrylonitrile Copolymer | Appearance: | Yellow Opaque Spherical Beads |
|---|---|---|---|
| Particle Size Range: | 0.315-1.25 Mm (95% Minimum) | Shipping Weight: | 0.72-0.87 G/ml |
| Moisture Content: | 60-70% | Sphericity After Attrition: | 90% Minimum |
| Gallium Adsorption Capacity: | 3.5 G/L Minimum | Application: | Ga Extraction From Bayer-Process Alumina Mother Liquor |
| Highlight: | Chelating Resin Gallium Elution,Sodium Sulfide Caustic Regeneration Resin,Chelating Resin 3.5g/L Capacity |
||
Product Description
Product Introduction
Sphelite ACD-800B is a macroporous chelating resin on a styrene-acrylonitrile copolymer matrix whose grafted functional groups selectively bind gallium ions (Ga3+) by chelation. The resin is designed for alkaline elution circuits: a mixed Na2S·9H2O and NaOH regenerant strips gallium, followed by a 5.0mol/L NaOH activation step that restores the chelating groups for the next loading cycle.
Technical Indexes
| Appearance | Yellow opaque spherical beads |
| Structure | Styrene-Acrylonitrile Copolymer |
| Particle Size Range (mm) | ≥ 95% 0.315-1.25 |
| Shipping Weight (g/ml) | 0.72-0.87 |
| Moisture Content (%) | 60-70 |
| Sphericity after Attrition (%) | ≥ 90 |
| Gallium Adsorption Capacity (g/L) | ≥ 3.5 |
Regeneration Cycle
- Mixed eluent: 4~6BV of 0.8333mol/L Na2S·9H2O + 2.5mol/L NaOH.
- Activation: 2BV of 5.0mol/L NaOH.
- Flowrates: 1-1.5BV/h for the mixed eluent, 2BV/h for water and NaOH.
- Rinse with 2~4BV pure water twice before elution and prior to NaOH activation.
Operating Conditions
Pre-treatment: Rinse resin with 1-2BV pure water.
Adsorption Conditions: SS ≤ 1 ppm.
Regeneration:
- Regenerants: 4~6BV mixed solution (0.8333mol/L Na₂S·9H₂O + 2.5mol/L NaOH) and 2BV 5.0mol/L NaOH
- Concentration: 0.8333mol/L Na₂S·9H₂O + 2.5mol/L NaOH, 5.0 mol/L NaOH
- Flowrates: 1-1.5BV/h (mixed eluent), 2BV/h (water & NaOH)
- Rinse resin with 2~4BV pure water twice before elution and prior to NaOH activation
Key Applications
- "Ga" extraction from Bayer-process alumina mother liquor
- "Ga" recovery from alkaline sodium aluminate liquor
- "Ga" enrichment from various alkaline liquid systems
Storage Proposal
The storage temperature of this material shall not be higher than 90°C. Stored above 0°C in wet state. In the storage state, keep the package sealed well to prevent water loss. In case of water loss, soak the dry resin in ethanol for about 2 hours, wash it with clean water and then repackage or use it. Prevent the spheroid from freezing and cracking in winter. If freezing is found, melt slowly at room temperature.
Packaging
ADVSORBENT provides a variety of packaging options, such as bags, drums, cartons, bulk bags and ton bags that meet the transportation standards at home and abroad. We also accept customized packaging according to customer requirements to ensure the safe and efficient delivery of products to each customer: 25 liters/bag · 25KG/bag · 50 liters/drum (dry type) · 200 liters/drum · 1 cbm on a pallet · 1 Ton on a pallet.
